4. P o w e r P a c k 350 bar
| Anwendungen: |
|---|
|
Schneid-Systeme
Reinigung-Systeme
|
| Nr. | Definition | Techn. specification |
|---|---|---|
| 1. | Presure max. | 350 bar 250 bar 200 bar |
| 2. | flow rate | 17,8 l/min 21 l/min 21 l/min |
| 3. | power | 11 kW (15 kW) |
| 4. | size | b x l x h = 800 x 665 x 1240 mm |
| 5. | consumer | 1, 2, 3, 4, ....... |
| 6. | max. temperature | 70 Grad Celsius |
| 7. | piston diameter | 18 mm |
| 9. | stroke of the piston | 20 mm |
| 10. | pressure controll | remote control |
